Back in the late 60s the G12H was created by fixing an ‘H’ type (heavy) magnet to the body of a G12M guitar speaker. Result: a speaker with more power and a different tonal balance: firmer bass and a more pronounced top end. So we added an ‘H’ magnet to the G12M-65 Creamback to create a guitar speaker that delivers the sonic signature of a G12H combined with Creamback levels of power handling. The result is the G12H-75 Creamback. It delivers 75-watts of power handling with ease and has unmistakeable G12H tone with a tighter low end than the G12M-65 Creamback and a punchier more dynamic high end. The H magnet brings additional focus body and girth to the Creamback tone. It thickens single notes resulting in a highly articulate vocal character. These additional characteristics mean that the G12H-75 Creamback offers exceptional performance when used for lead guitar and sounds massive loaded into a 4×12 cab!
General Specifications
Nominal diameter | 12", 305mm |
Power rating | 75Wrms |
Nominal impedance | 8Ω & 16Ω |
Sensitivity | 100dB |
Chassis type | Pressed steel |
Voice coil diameter | 1.75", 44.5mm |
Voice coil material | Round copper |
Magnet type | Ceramic |
Magnet weight | 50oz, 1.42kg |
Frequency range | 70-5000Hz |
Resonance frequency, Fs | 75Hz |
DC resistance, Re | 6.77Ω & 12.5Ω |
Mounting Information
Cut-out diameter | 11.1", 283mm |
Diameter | 12.2", 309mm |
Magnet structure diameter | 6.6", 168mm |
Mounting slot dimensions | Ø 0.31in/7.9mm |
Mounting slot PCD | 11.7", 297mm |
Number of mounting slots | 8 |
Overall depth | 5.4in/138mm |
Unit weight | 10.4lb/4.7kg |
