Slam Latch for Slam-Lid System. Easy assembly - Drill or route a finger hole and attach Slam Latch aligned on inside of the lid. To release lid insert finger and disengage the latch and pull the lid off. Part No: L2470

Large Dish with Vertical Louvre. Part No. D0536 Z Material 1.2mm Steel Finish PennBrite Dish Depth 16mm Weight 0.25kg

Dish Punched for 2 x Neutrik D-Series Connectors (XLR, Speakon, RJ45, etc.) Part No. D023K Material 1.2mm Steel Finish Black Dish Depth 16mm Weight 0.25kg

Long Black Plastic Foot Sold individually. Part No. F1699/LD Material Plastic Finish Black Length 35mm Width 12mm Height 8mm Weight 20g

Low noise 3U Heat Extraction Units are designed to be fitted into the front or back of a 19-inch rack to suck hot air out of an enclosure. As hot air rises the best results will be achieved by mounting them at the top of the cabinet. A DC-DC link socket is provided, so two or more units can be linked together; a higher power PSU must be used . Each extractor can also be controlled by a CRC-TEMP thermal sensor. Technical Specifications • Low Noise 22.5dBA (0.3 Sone) • Air movement: 200CFM (336m³/h) @1,350RPM • Dimensions: 483mm x 133.4mm x 55mm • 2 x 9 Bladed 120mm Fans • High Static Pressure • Power: 12V DC – 500mA / 2 x DC In/Out Sockets • 500mA universal PSU supplied • Fluid Bearings = 2 Year Limited Warrantee These extractor panels can be controlled by our CRC-TEMP Standard Fixed 40°C (104°F) thermal sensor. Or they can be Digitally Controlled by our FT-DTC 1U Rack Mounting Thermostatic Controller. Use AF-F12 Magnetic Fan Dust Filter Covers. Part No. FP02-Q-3U Finish Black Description 3U Heat Extraction Panel Weight 1.5kg

Female PennBrite Zinc Lid Hang This two-piece dish kit is a clever solution for outfitting cases with convenient and unobtrusive hooks to hang a removable lid on when not on the case. This solves the problem of needing to stack many lids in a separate location as well as eliminating the possibility of mixing lids with cases. The H7148-CUP-M and H7148-CUP-F may also be used to couple cases together in a train formation. The hook and hang system lets you train many cases together to roll as one when transporting them across locations. How to use: The lid-fitted H7148-CUP-M is a swing-out handle dish that has a near-flush profile when not in use. The lid can be removed by pulling the handle out, lifting the lid off and then hanging it on the panel-fitted H7148-CUP-F hook dish. Smaller cases may use just one centrally-fitted kit while larger cases can utilise two kits for a double hook. Material Steel Weight 193g Finish Zinc Gender Female

Male PennBrite Zinc Lid Hang This two-piece dish kit is a clever solution for outfitting cases with convenient and unobtrusive hooks to hang a removable lid on when not on the case. This solves the problem of needing to stack many lids in a separate location as well as eliminating the possibility of mixing lids with cases. The H7148-CUP-M and H7148-CUP-F may also be used to couple cases together in a train formation. The hook and hang system lets you train many cases together to roll as one when transporting them across locations. How to use: The lid-fitted H7148-CUP-M is a swing-out handle dish that has a near-flush profile when not in use. The lid can be removed by pulling the handle out, lifting the lid off and then hanging it on the panel-fitted H7148-CUP-F hook dish. Smaller cases may use just one centrally-fitted kit while larger cases can utilise two kits for a double hook. Material Steel Weight 266g Finish Zinc Gender Male

Cover plate for L2455 Small Slam Latch. - An aesthetic finish: once mounted over the slam latch access hole, the cover plate creates a professional and flawless appearance - Save time: thanks to its indent, the plate covers the exposed edges of the access hole, providing a smooth finish without the need to sand Part No. L2455/MBZ Material 1mm Steel Weight 10g

The new R5033X is a door hinge mounted on a 555mm drawer slide that allows you to slide a trap door within a rackmount case when in use. With a simple panel and a slam lock, you can easily create a door that can be hidden within the case when opened. Perfect to build standard 600mm x 600mm shock mount rack cases For use with R8800 Anti-Vibration Rack Systems: the easiest way to build a shock mount rack case. Use crossbar R8800-70 for additional space to fit the sliding door. R50335 - For use with 30mm extrusions. R50338 - For use with 35mm extrusions. Sold in Pairs Extended Load Capacity: 10kg per pair Part No. R50335 & R50338 Material Steel Finish Zinc Description Door Hinge on Drawer Slide

2 Leg Cranked Wrap-Around Corner for Slam-Lid System. Works with Slam Latch L2470, Extrusion E0490-4M and Hook P2472 Part No. C0675/30 Material 1.0mm Steel Finish Zinc Weight 37g

Small Slam Latch for Slam-Lid System. Easy assembly - Drill or route a finger hole and attach Slam Latch aligned on inside of the lid. To release lid insert finger and disengage the latch and pull the lid off. 65% the size of L2470 Use Cover Plate L2455/MBZ for a professional and flawless appearance Can be used with Extrusion E0490, Corner C0675/30 and Hook P2472 Part No. L2455 Description Slam Latch Weight 57g

19" Black Rack Mounting Bracket. Sold individually. Material 1.5mm Steel Size (U) 1U Weight 82g

6U Black Perforated Flanged Rack Panel. Allow for 62% free air. Material 1.2mm Steel Type Flanged Size (U) 6U Weight 615g Finish Black

5U Black Perforated Flanged Rack Panel. Allow for 62% free air. Material 1.2mm Steel Type Flanged Size (U) 5U Weight 605g Finish Black

Rack Shelf Support, to suit R0883 . Sold individually. Part No. Finish Length Weight R0855K Black 305mm 0.3kg R0856K Black 406mm 0.34kg R0857K Black 508mm 0.43kg R0858K Black 610mm 0.52kg

Pre cut rack strip, 2mm, double, full hole, black, 34U - Sold as a pair. Full Hole Double Rack Rail with Square Holes. Cuts from 1 space 44.45mm / 1.75" to 45 spaces 2m / 79" are available. Mounting Equipment on Rails: -Use our new and innovative Clip Nuts on Rack Rails For an easy and economic alternative. -Also compatible with S1170/ S1172 Captive Nuts, S1045 M6 Screws and S1940 - S1941 Cup Washers.

Pre cut double rack strip, full hole, black, 26U - Sold as a pair. Mounting Equipment on Rails: -Use our new and innovative Clip Nuts on Rack Rails for an easy and economic alternative. -Also compatible with S1170 Captive Nuts, S11160 M6 Screws and S1940 and S1941 Cup Washers. Part No. R0883-26 Material 1.5mm Steel Finish Black Rack Units 26U

Pre cut double rack strip, full hole, black, 24U - Sold as a pair. Mounting Equipment on Rails: -Use our new and innovative Clip Nuts on Rack Rails for an easy and economic alternative. -Also compatible with S1170 Captive Nuts, S11160 M6 Screws and S1940 and S1941 Cup Washers. Part No. R0883-24 Material 1.5mm Steel Finish Black Rack Units 24U

Pre cut double rack strip, full hole, black, 22U - Sold as a pair. Mounting Equipment on Rails: -Use our new and innovative Clip Nuts on Rack Rails for an easy and economic alternative. -Also compatible with S1170 Captive Nuts, S11160 M6 Screws and S1940 and S1941 Cup Washers. Part No. R0883-22 Material 1.5mm Steel Finish Black Rack Units 22U

Pre cut double rack strip, full hole, black, 20U - Sold as a pair. Mounting Equipment on Rails: -Use our new and innovative Clip Nuts on Rack Rails for an easy and economic alternative. -Also compatible with S1170 Captive Nuts, S11160 M6 Screws and S1940 and S1941 Cup Washers. Part No. R0883-20 Material 1.5mm Steel Finish Black Rack Units 20U

Pre cut double rack strip, full hole, black, 18U - Sold as a pair. Mounting Equipment on Rails: -Use our new and innovative Clip Nuts on Rack Rails for an easy and economic alternative. -Also compatible with S1170 Captive Nuts, S11160 M6 Screws and S1940 and S1941 Cup Washers. Part No. R0883-18 Material 1.5mm Steel Finish Black Rack Units 18U

Pre cut double rack strip, full hole, black, 16U - Sold as a pair. Mounting Equipment on Rails: -Use our new and innovative Clip Nuts on Rack Rails for an easy and economic alternative. -Also compatible with S1170 Captive Nuts, S11160 M6 Screws and S1940 and S1941 Cup Washers. Part No. R0883-16 Material 1.5mm Steel Finish Black Rack Units 16U

Pre cut double rack strip, full hole, black, 14U - Sold as a pair. Mounting Equipment on Rails: -Use our new and innovative Clip Nuts on Rack Rails for an easy and economic alternative. -Also compatible with S1170 Captive Nuts, S11160 M6 Screws and S1940 and S1941 Cup Washers. Part No. R0883-14 Material 1.5mm Steel Finish Black Rack Units 14U

Pre cut double rack strip, full hole, black, 12U - Sold as a pair. Mounting Equipment on Rails: -Use our new and innovative Clip Nuts on Rack Rails for an easy and economic alternative. -Also compatible with S1170 Captive Nuts, S11160 M6 Screws and S1940 and S1941 Cup Washers. Part No. R0883-12 Material 1.5mm Steel Finish Black Rack Units 12U

Pre cut double rack strip, full hole, black, 10U - Sold as a pair. Mounting Equipment on Rails: -Use our new and innovative Clip Nuts on Rack Rails for an easy and economic alternative. -Also compatible with S1170 Captive Nuts, S11160 M6 Screws and S1940 and S1941 Cup Washers. Part No. R0883-10 Material 1.5mm Steel Finish Black Rack Units 10U

Pre cut double rack strip, full hole, black, 9U - Sold as a pair. Mounting Equipment on Rails: -Use our new and innovative Clip Nuts on Rack Rails for an easy and economic alternative. -Also compatible with S1170 Captive Nuts, S11160 M6 Screws and S1940 and S1941 Cup Washers. Part No. R0883-09 Material 1.5mm Steel Finish Black Rack Units 9U

Pre cut double rack strip, full hole, black, 8U - Sold as a pair. Mounting Equipment on Rails: -Use our new and innovative Clip Nuts on Rack Rails for an easy and economic alternative. -Also compatible with S1170 Captive Nuts, S11160 M6 Screws and S1940 and S1941 Cup Washers. Part No. R0883-08 Material 1.5mm Steel Finish Black Rack Units 8U

Pre cut double rack strip, full hole, black, 7U - Sold as a pair. Mounting Equipment on Rails: -Use our new and innovative Clip Nuts on Rack Rails for an easy and economic alternative. -Also compatible with S1170 Captive Nuts, S11160 M6 Screws and S1940 and S1941 Cup Washers. Part No. R0883-07 Material 1.5mm Steel Finish Black Rack Units 7U

Pre cut double rack strip, full hole, black, 6U - Sold as a pair. Mounting Equipment on Rails: -Use our new and innovative Clip Nuts on Rack Rails for an easy and economic alternative. -Also compatible with S1170 Captive Nuts, S11160 M6 Screws and S1940 and S1941 Cup Washers. Part No. R0883-06 Material 1.5mm Steel Finish Black Rack Units 6U

Pre cut double rack strip, full hole, black, 5U - Sold as a pair. Mounting Equipment on Rails: -Use our new and innovative Clip Nuts on Rack Rails for an easy and economic alternative. -Also compatible with S1170 Captive Nuts, S11160 M6 Screws and S1940 and S1941 Cup Washers. Part No. R0883-0 Material 1.5mm Steel Finish Black Rack Units 5U

Pre cut double rack strip, full hole, black, 4U - Sold as a pair. Mounting Equipment on Rails: -Use our new and innovative Clip Nuts on Rack Rails for an easy and economic alternative. -Also compatible with S1170 Captive Nuts, S11160 M6 Screws and S1940 and S1941 Cup Washers. Part No. R0883-04 Material 1.5mm Steel Finish Black Rack Units 4U

Pre cut double rack strip, full hole, black, 3U - Sold as a pair. Mounting Equipment on Rails: -Use our new and innovative Clip Nuts on Rack Rails for an easy and economic alternative. -Also compatible with S1170 Captive Nuts, S11160 M6 Screws and S1940 and S1941 Cup Washers. Part No. R0883-03 Material 1.5mm Steel Finish Black Rack Units 3U

Full Hole Double Rack Rail with Square Holes . Cuts from 1 space 44.45mm to 45 spaces 2m are available. See our other product listings. Mounting Equipment on Rails: -Use our new and innovative Clip Nuts on Rack Rails for an easy and economic alternative. -Also compatible with S1170 / S1172 Captive Nuts, S1045 M6 Screws and S1940 - S1941 Cup Washers. Part No. R0883 Material Steel Finish Black Thickness 1.5mm Description From 1 Space to 45 Spaces Weight 1.9kg

Pre cut rack strip, full hole, black, 24U - Sold as a pair. Mounting Equipment on Rails: -Use our new and innovative Clip Nuts on Rack Rails for an easy and economic alternative. -Also compatible with S1170 Captive Nuts, S11160 M6 Screws and S1940 and S1941 Cup Washers. Part No. R0863-24 Material 1.5mm Steel Finish Black Rack Units 24U

Pre cut rack strip, full hole, black, 22U - Sold as a pair. Mounting Equipment on Rails: -Use our new and innovative Clip Nuts on Rack Rails for an easy and economic alternative. -Also compatible with S1170 Captive Nuts, S11160 M6 Screws and S1940 and S1941 Cup Washers. Part No. R0863-22 Material 1.5mm Steel Finish Black Rack Units 22U

Pre cut rack strip, full hole, black, 20U - Sold as a pair. Mounting Equipment on Rails: -Use our new and innovative Clip Nuts on Rack Rails for an easy and economic alternative. -Also compatible with S1170 Captive Nuts, S11160 M6 Screws and S1940 and S1941 Cup Washers. Part No. R0863-20 Material 1.5mm Steel Finish Black Rack Units 20U
