Vented Rack Shelf with CNC cut Magnetic Faceplates for a variety of SONOS Components. Custom Front Panels available for any piece of equipment on the market such as AV equipment or game consoles. Each Kit includes: - 1 x Vented Rack Shelf with Magnets for Faceplates - 1 x CNC cut Faceplates - 1 x Clamp Bar to help secure your equipment *SONOS Components NOT Included Part No. R1498/2UK-SONAMP2 Material 1.2mm Steel Finish Black Size (U) 2U Application 2 X SONOS AMP Weight 3.2kg

Vented Rack Shelf with CNC cut Magnetic Faceplates for a variety of SONOS Components. Custom Front Panels available for any piece of equipment on the market such as AV equipment or game consoles. Each Kit includes: - 1 x Vented Rack Shelf with Magnets for Faceplates - 1 x CNC cut Faceplates - 1 x Clamp Bar to help secure your equipment *SONOS Components NOT Included Part No. R1498/2UK-SONPT Material 1.2mm Steel Finish Black Size (U) 2U Application 1 X SONOS PORT & 1 X SONOS AMP Weight 3.2kg

Handle for use in H1024 & H1027 ABS Bodies. Available in Die-Cast Aluminium or Plastic with Steel insert. Name Tags plain, or printed to your specification (at extra cost). Part No. H1024HK Material Die-Cast Aluminium Handle Weight 0.1kg

Bar Handle with Die-Cast Handle and ABS Plastic Body. Name Tags plain, or printed to your specification (at extra cost). Part No. H1024 Material ABS Plastic/Die-Cast Aluminium Weight 0.18Kg

Heavy Duty Corner Protector, PVC with Steel Insert. Part No. Finish Description Weight 5387GREY Grey PVC/Steel 0.16kg

Slotted Catch Plate for Large Butterfly Catch Part No. Finish Weight 0371 Zinc 32g

Large Surface Mount Twist Latch 7568 Pre-Riveted into 2017 protector plate with protective ridges. 2017 protector plate also sold separately Use Keeper Plate 0371 (Not Included). Part No. Finish Weight 2017-7568 Zinc 0.33kg

Medium Latch with Lid Catch Plate. For use with wooden crate panels 18mm Part No. Finish L905/55/915Z PennBrite

Pallet Collar Hinge with Removable Pin 220mm x 87mm x 1.5mm Part No. Finish Weight P1390GLV Galvanized 0.43 Kg

Pallet Cushion Spacer to Suits 7035 - 7225 Pallet Cushions. Spacer Height: 28.6mm Increases cushion height to 102mm

Series 7 Air-Dampened Pallet Cushions. Cushion Height: 2-7/8" / 73mm Cushion + Spacer = 4” / 102mm Use Spacer 7228 Our Pallet Cushions are the most economical and reliable way to replace and upgrade wooden skid runners on pallet crates, eliminating the need for costly air-ride trucks, these air-dampened polyethylene cushions are easily attached to pallets or crates to provide a high level of protection from shock and vibration. Don’t risk shipment damage by shocks, drops, and impact during transit or handling. Easy to Install The pre-installed t-nut, with a 5/16”-18 UNC thread, protrudes out of the cushions for easy location into the mounting hole and fast installation. (Also available with an M8 threaded t-nut or without t-nut) The pallet cushions are mounted directly on a pallet or container base with a simple bolt. Reusable The pallet cushions can be easily removed and mounted again on another pallet. Simple and Practical Our Series 7 Pallet Cushions, once fitted with the 7228 Spacer, create a four-way 4” space under the pallet, which makes it easy to load and unload with a pallet jack and forklift. Textured Finish The Series 7 Pallet Cushions has a textured finish for a better grip. Resistant and Durable Our Pallet Cushions have been through rigorous stress tests. They can be dragged on concrete and joints for 3000 feet, at maximum load, with only minimal wear noted. Suitable for use between -104°F and +130°F (-40°C to + 54°C) and chemical resistant. Independent Test Reports MSDS for Cushions MSDS for Raw Material Part No. Finish Load Capacity Fixing Weight 7035-M8 Tan 9.1 - 15.9 Kg M8 0.11 Kg 7050-M8 Green 13.6 - 22.7 Kg M8 0.13 Kg 7080-M8 Yellow 20.4 - 36.3 Kg M8 0.16 Kg 7125-M8 Blue 31.8 - 56.7 Kg M8 0.19 Kg 7225-M8 Orange 56.7 - 102 Kg M8 0.24 Kg

Large pallet skid. 116mm x 90mm Allows cases without wheels or with removable wheels to be handled with fork lift or pallet truck. Part No. Material Length Weight E0090 3.25mm Aluminum 4m 9.44

Set of 4 Steel Adjuster Feet with M8 thread for Rack Enclosures. Use with R8230 Open Tower Rack System, R2020 Modular Rack Tower, R8200 Open Rack Tower System, R8400 - R8500 Flat Pack Rack System, R6400 and R6600 Wall Mount Racks.

Simple flat pack / knock-down open tower rack system. Works with R0863 or R0883 rack strip (minimum 4U) for any size or depth rack. Optional adjustable feet F3000 and castor kits R8480 or R2020-CASTOR-KIT are available. Material: 2mm / 0.08" Steel Part No. Finish Description Material R8230-TB Black Top & Base Kit 2mm Steel

Cabinet Corner 2 Leg with plain holes. Part No: C1270 Finish: Black Or PennBrite Internal Radius: 5mm Weight: 27g

Wall Mount Kit for Credenza Racks & Sleeves. For Credenza Wood Racks Kits 8U high or more, use two kits (2 brackets on each side). For use with Beech and Knotty Oak finish racks. Not compatible with Nebraska Oak and Tiepolo Walnut finishes. Part No. Description WMKCZ Wall Mount Kit for Credenza Racks & Sleeves

Tinted PlexiGlass Full Width Doors with key lock for Credenza Wood Racks. For use with Beech and Knotty Oak finish racks. Not compatible with Nebraska Oak and Tiepolo Walnut finishes. Part No. Size (U) Description R8600-CZD4-FW 4U Smoked PlexiGlass Full Width Doors R8600-CZD6-FW 6U Smoked PlexiGlass Full Width Doors R8600-CZD8-FW 8U Smoked PlexiGlass Full Width Doors R8600-CZD12-FW 12U Smoked PlexiGlass Full Width Doors

Smoked Plexiglass Barn Doors for Credenza Wood Racks For use with Beech and Knotty Oak finish racks. Not compatible with Nebraska Oak and Tiepolo Walnut finishes. Assembly Guide Part No. Size (U) Description R8600-CZD4S 4U Smoked Plexiglass Barn Doors R8600-CZD6S 6U Smoked Plexiglass Barn Doors R8600-CZD8S 8U Smoked Plexiglass Barn Doors R8600-CZD12S 12U Smoked Plexiglass Barn Doors

250mm Deep Beech Wood laminate rack sleeves with M6 threaded rack rails. Made from high quality 18mm laminate boards. Perfect for use in studios, offices, boardrooms, churches, etc. The mounting rails can be recessed up to 60mm for more space behind the door, additional R0863 rails can be fitted at the back. Set of 4 non-marking feet included. Optional smoked plexiglass Credenza Barn Doors and Credenza Full Width Doors available for the 4U units only. Wall Mount Kit WMKCZ available. Dimensions: - Depth: 250mm - Width: 531mm Finish: Beech Part No. Finish Description Size (U) Height R8600-250-1U Beech Credenza Wood Rack Sleeve 1U 85mm R8600-250-2U Beech Credenza Wood Rack Sleeve 2U 129mm R8600-250-3U Beech Credenza Wood Rack Sleeve 3U 174mm R8600-250-4U Beech Credenza Wood Rack Sleeve 4U 219mm

Flat pack / knock-down 450mm Deep Beech Wood laminate rack kits with M6 threaded rack rails. Made from high quality 18mm laminate boards. Perfect for use in studios, offices, boardrooms, churches, etc. The mounting rails can be recessed up to 60mm for more space behind the door, additional R0863 rails can be fitted at the back. Set of 4 non-marking feet included. Optional smoked plexiglass Credenza Barn Doors and Credenza Full Width Doors available. Wall Mount Kit WMKCZ available. Dimensions: - Depth: 450mm - Width: 531mm Finish: Beech Part No. Finish Description Size (U) Height R8600-450-4U Beech Credenza Rack 4U 219mm R8600-450-6U Beech Credenza Rack 6U 308mm R8600-450-8U Beech Credenza Rack 8U 397mm R8600-450-12U Beech Credenza Rack 12U 575mm

Slam shut rear panel system for contractor racks. Comprised of 3 sizes that work together to create all of the rack sizes available in our range. All Panels are vented and include a 1U space for blank, vented, or cable access rack panels. Part No. Size (U) Description RP06 6U Contractor Rear Panels RP08 8U Contractor Rear Panels RP12 12U Contractor Rear Panels

Replacement Barrel Lock & Key For RCXX600 Series Contractor Flat Pack Rack System Doors.

Locking front doors for the contractor rack series are available in smoked grey polycarbonate or vented steel. Product comes fully assembled with barrel locks and 2 keys, and can be retrofitted after installation. Replacement keys are available as they are all keyed alike. Contractor Smoked Polycarbonate Doors: Part No. Finish Size (U) PGRD06C Black 6U PGRD08C Black 8U PGRD12C Black 12U PGRD16C Black 16U PGRD20C Black 20U PGRD24C Black 24U PGRD28C Black 28U PGRD32C Black 32U PGRD35C Black 35U Contractor Vented Doors: Part No. Finish Size (U) RD06C Black 6U RD08C Black 8U RD12C Black 12U RD16C Black 16U RD20C Black 20U RD24C Black 24U RD28C Black 28U RD32C Black 32U RD35C Black 35U

Castor base kit for contractor, wood shell and credenza racks. Comprised of 4 heavy duty 70mm castors with fixings. Contractor castor base kit includes MDF load-bearing panels. Max load rating: 150kg. Part No. Description RCB-600B Braked Castor Base for Contractor Racks

Flat pack / knock-down 457mm / 17.99" and 600mm / 23.62" deep rack enclosures with stylish, modern appearance. - Overall width: 543mm / 21.38" - Front and rear mounting rails - Well ventilated top, base, front sections - Ventilation on side panels for 600mm / 23.62" deep models - Pre punched for Contractor castor base kit - Optional lockable Contractor front doors - Optional RP Contractor Rear Panels - Flat pack / knock-down and easy assembly. Part No. Finish Size (U) Depth Internal Depth R12C600 Black Texture 12U 600mm 560mm R16C600 Black Texture 16U 600mm 560mm R20C600 Black Texture 20U 600mm 560mm R24C600 Black Texture 24U 600mm 560mm R28C600 Black Texture 28U 600mm 560mm R32C600 Black Texture 32U 600mm 560mm R35C600 Black Texture 35U 600mm 560mm

High Quality, 450mm Deep, Wall Mount Rack Enclosures with: - Threaded Rack Rails -Integrated Internal Cable Management System -3-Fan Vents on the top -Cable Knock-Outs on the top, back and base -Lockable Front Door (choose from a Smoked Polycarbonate Door or Perforated Steel Door) Also Available in White by request. Replacement Doors Available Part No. R6406V-M6 Material Steel Finish Black Size (U) 6U, 9U, 12U, 18U Rack Rails M6 Door Vented Height 6U - 367mm 9U - 50mm 12U - 633mm 18U - 900mm

The new R6400-RHF rear hinged frame turns wall mount cabinets into hinged double section cabinets. With a depth of only 152mm, the bracket is an unobtrusive fixture that can easily support the weight of a fully loaded rack, and enables it to securely swing away from the wall. This gives installation professionals unrivalled accessibility to the rear of the rack, making it easier than ever to run cables, replace equipment parts, or keep up general maintenance of the rack's contents. The slam shut system also creates an easy to use open/close function. The bracket is available for 6U, 9U, 12U and 18U racks. Compatible with: - R6425 / R6525 250mm / 10" Deep Wall Mount Enclosures - R6400 400mm / 18" Deep Wall Mount Enclosures - R6600 600mm / 24" Deep Wall Mount Enclosures Part No. R6400-RHF Material Steel Finish Black Size (U) 6U, 9U, 12U, 18U

Flat Pack / knock-down Rack System with Square Hole Rails (R8400 Series) or 10/32 UNF Threaded Rails (R8500 Series). - Use R0856K for rack shelf support. - Suitable fasteners for racking equipment are S1170 , SM6/HP . - Can be fitted with castors or M8 adjuster feet (not included). - For light duty, use R8480 castor set. - For larger systems use W0980 and W0980/B or W0990/80 and W0985/80 . Part No. Finish Size (U) Height Depth Internal Depth Weight R8400-06 Black 6U 320.1mm 480mm 450mm 10.5kg R8400-08 Black 8U 409mm 480mm 450mm 14kg R8400-10 Black 10U 497.9mm 480mm 450mm 15.5kg R8400-12 Black 12U 586.8mm 480mm 450mm 17kg R8400-16 Black 16U 764.6mm 480mm 450mm 21kg R8400-20 Black 20U 942.4mm 480mm 450mm 25kg R8400-24 Black 24U 1.12m 480mm 450mm 29kg R8400-28 Black 28U 1.27m 480mm 450mm 33kg R8400-35 Black 35U 1.61m 480mm 450mm 37.5kg

Rack box with removable back panel, 3mm Front Panel, and Vented Top. Black with choice of Brushed Black Anodised or Brushed Silver Anodised Front Panel. Part No. R2130/xx Size 1U, 2U, 3U, 4U Depth 300mm Material 1.2mm Steel

Rack box with removable back panel, 3mm Front Panel, and Vented Top. Black with choice of Brushed Black Anodised or Brushed Silver Anodised Front Panel. Part No. R2120/xx Size 1U, 2U, 3U, 4U Depth 220mm Material 1.2mm Steel

Rack box with a 3mm Aluminium Front Panel, and Vented Top. Part No. R2110 /4UK Material 1.2mm Steel Finish Black Depth 300mm Size (U) 4U Weight 3.51kg

Rack box with a 3mm Aluminium Front Panel, and Vented Top. Part No. R2110 /3UK Material 1.2mm Steel Finish Black Depth 300mm Size (U) 3U Weight 3.51kg

Rack box with a 3mm Aluminium Front Panel, and Vented Top. Part No. R2110 /2UK Material 1.2mm Steel Finish Black Depth 300mm Size (U) 2U Weight 3.63kg

Rack box with a 3mm Aluminium Front Panel, and Vented Top. Part No. R2110 /1UK Material 1.2mm Steel Finish Black Depth 300mm Size (U) 1U Weight 3.51kg

8mm / 5/16" ex Wrench Actuation Tool for Panel Locks. Use with 9284M Panel Lock. Part No. 9608 Material Steel

Panel lock, Male. Use with 9284F - Sold separately. Mounting style: mortise mount or side mount Use with hex wrench actuation tool 9608 Part No. 9284F Material 1.5mm Steel Description Male Lock style roto-lock Load Rating 700kg Weight 0.23kg
