2U Rack Mountable Digital Thermostatically Controlled Quiet Fan Exhaust unit, for use in 19” equipment racks. It has been designed be fitted in-between equipment or at the top of the rack to expel hot air efficiently and quietly. Technical Specifications Continuous temperature monitoring Set & forget fan control Fan run LED indicator Over temperature alarm Temperature Sensor Input Socket Plug-in PTC sensor 1m lead Low Noise (24.4 dBA) 12V DC Operation - 500mA 3 x 9 Bladed Swiss 120mm Fans 220 CFM / 378m³/h Japan made Fluid Bearings Temperature Sensor Input Socket DC in/out sockets 1A universal PSU supplied Part No. CRC02-DTC Material Steel Finish Black Description Thermo Exhaust Blower Dimensions (OD): 44.5mm x 483mm x 222mm Weight 1.4kg

This is a very quiet 1U Hot Air Extraction Unit, which uses 3 miniature blowers to expel heat from any 19” equipment racks. Behind the 1U Escutcheon, the ergonomic 0.5U space design allows for the CoolRaC to be placed in between layers of equipment to pull heat directly away from the gear. Technical Specifications Low Noise: 22.3dBA (Ideal for Studio Racks & Churches) Power: 12V DC - 420mA Air movement: 120 CFM 1A Universal PSU included. Black Powder Coated 1mm Steel Construction Available accessories: This CoolRaC can be controlled by our CRC-TEMP Standard Fixed 40°C (104°F) thermal sensor. Or it can be Digitally Controlled with our FT-DTC 1U Rack Mounting Thermostatic Controller. DC link cable: CRC-Link Part No. COOLRAC -B Finish Black Description 1U Hot Air Extraction Unit Weight 1.83kg

2U 16amp Rack Mount PDU with Power Monitor Pair of C-FORM Sockets with overload trip switch. 8 x Neutrik PowerCon Outlet Sockets with 16A overload trip switch. Ideal solution for fast power distribution in stage, studio, and touring environments. Circuit A - Main Input: C-FORM 240V 16A IP44 Panel Mount Appliance Inlet - Protection: Illuminated Circuit Breaker overload protection between dual 16A sockets - Output: C-FORM 240V 16A IP44 Panel Mount Appliance Outlet Circuit B - Output: 8 Neutrik powerCon sockets with a Maximum Combined Load 16A. - Protection: Illuminated Circuit Breaker 16A overload protection - LCD Monitor: LCD Power Monitor giving Voltage, Current , Power, Energy Levels & Overload Alarm. - Earth Link: M4 Screw Terminal for Rack Grounding Usage - Nominal Voltage: 110V-240V - Usable Voltages 110V~240V full range - Frequency: 50/60HZ full range - Max. A/C Output: Current 16A - Case Size: 87mm x 98mm x 430mm / 3.43" x 3.86" x 16.93" Compliance: All components used in this conform to current RoHS, CE & UL certification - E&OE (EMI:EN55022 (CISPR22) Class B; EN61000-3-2,3 EMS:EN61000-4-2,3,4,5,6,8,11; Light industry level, criteria A) Part No. PDU16-PC Finish Black Description 2U 16amp Rack Mount PDU with PowerCon Outputs Weight 2kg

1U Rack Mounting PDU with Surge Protection & EMI Filter. Designed to provide a versatile hook-up for the distribution of AC & DC power within multimedia racking applications. All components used in this unit conform to current RoHS, CE & UL certification. Case Size: 45mm x 140mm x 430mm DC PSU: Switchable Isolated DC supply Earth Link: M4 Screw Terminal for rack grounding. Frequency: 50/60Hz Input: Neutrik Power Con with Internal 20A line Fuse, 20A EMI filter & GDC/MOV Lightning Strike/Power Surge Protection Max. A/C Output: Current 20A Nominal voltage: 230V Output AC: 8 x IEC320 C13 Output DC: 12 Way pluggable screw terminal socket. 3 x 5V dc max load 2100mA. 3 x 12V dc max load 1200mA. Protection: 2 x 10 Amp Circuit Breakers Usable Voltages: 200V - 240V Part No. PDU01-14 Finish Black Description 1U PDU with Surge Protection & EMI Filter Weight 3.5kg

1U 16A 10-Channel Power Distribution Unit This model in the PDU16 series is a 1U distributor with ten switchable channels protected by an overload trip switch. Each numbered channel has a dedicated rocker switch with neon indicator light for quick and easy identification. The unit receives power through a C20 inlet and can output to ten C13 / IEC outlets. Each unit comes supplied with one 1.8m power cable. PDU16-10DJ -AU: Type 1 (10A for Australia, New Zealand, China & Argentina) Limited to 10A maximum load. For 16A use, replace with Blue C form. Part No. PDU16-10DJ-AU Finish Black Plug Type TYPE 1 (Australia, New Zealand, China & Argentina) Weight 2.5kg

Plastazote Foam - Black Premium quality Plastazote Foam Cut to size available upon request. Part No. M6030 Material LD29 High Density Polyethylene Thickness 30mm Full Sheet Size 2m x 1m Full Sheet Weight 1.61kg

100 x High Point Screws with Removable Plastic Washer Attached in Convenient Flip Top Container Part No. SM6 /HP/WA/100 Finish Black Description 100 x M6 High Point Screws with Removable Plastic Washer Attached in Flip Top Container

M6 Rack Screw Pack, which contains: 25 x S1172 M6 Cage Nuts for 2mm / 0.08" Rack Strips 25 x S1940 M6 Plastic Cup Washers 25 x M6 Pozi Pan Head Screws (see below) Part No. R0889K-25/20MM Material Steel/Plastic Finish Black Screw Size M6 x 20mm

High Point Screws. Easy insert into nuts due to their non-threaded ends. Each Screw comes with a Washer. Part No. SM6/HP Finish Black Description M6 High Point Screw with Plastic Washer included

Large Ball Corner with new interlocking cut-outs. Enables cases to stack and lock without slippage. Also available C7082-STACK medium flat corner. 3 Mounting Holes Additionally, the new L3000-7 case stacking latch allows to lockdown stacked cases, making it impossible for them to separate when moved around. This new system works perfectly with the new C1351 -STACK large ball corner with new interlocking cut-outs and makes handling and storing large amounts of case much easier. Part No. C1351 -STACK Material 1.5mm Steel Finish PennBrite Description large Ball corner Internal Radius 0.5mm Stackable Interlocking cut-outs Offset 30mm Weight 69g

New case stacking latch allows you to lock two cases together, ensuring they cannot separate. This latch system is designed to work with our new C1351-STACK large ball corner with interlocking cut-outs and makes handling and storing large amounts of cases much easier. Part No. L3000-7 Material Steel Finish PennBrite Description Case Stacking Latch

1U Rack Panel punched for 5 powerCON TRUE1 Chassis Connectors Punched for 1 NAC3MPX Inlet and 4 NAC3FPX Outlets Part No. R1268-1UK-05TR Material Steel Description Punched for 1 NAC3MPX Inlet and 4 NAC3FPX Outlets

1U Vertical Cable Retaining Clip (Sold as a Pair) Part No. CM01R Material Steel Finish Black Description Cable Retaining Clip

Stay in 10mm Deep Dish. Part No. D0559Z Material Steel Finish PennBrite Description Offset Dish Split Hole Centre Top 10mm / Bottom 13mm Offset 22mm Weight 0.34kg

Stage boxes punched for D-series connectors. Can be fitted with a multi-pin connector or cable gland (with adapter plate). Black Powder coated. Stage boxes are also available pre-filled with your choice of connectors. Part No. R2345-16 Material Steel Finish Black Description 16 Channel Stage Box Depth 260mm Width 153mm Height 65mm

Stage boxes punched for D-series connectors. Can be fitted with a multi-pin connector or cable gland (with adapter plate). Black Powder coated. Stage boxes are also available pre-filled with your choice of connectors. Part No. R2345-12 Material Steel Finish Black Description 12 Channel Stage Box Depth 260mm Width 113mm Height 65mm

Stage boxes punched for D-series connectors. Can be fitted with a multi-pin connector or cable gland (with adapter plate). Black Powder coated. Stage boxes are also available pre-filled with your choice of connectors. Part No. R2340-08 Material Steel Finish Black Description 12 Channel Stage Box Depth 380mm Width 55mm Height 63mm

Stage boxes punched for D-series connectors. Can be fitted with a multi-pin connector or cable gland (with adapter plate). Black Powder coated. Stage boxes are also available pre-filled with your choice of connectors. Part No. R2340-08 Material Steel Finish Black Description 8 Channel Stage Box Depth 265mm Width 55mm Height 63mm

Large MOL 3 Latch in Plain or Offset Dish With new Cantilever Automatic Open/Close function. Part No. L944/578MOL3 Material 1.2mm Steel Finish PennBrite Description Offset Dish Dish Depth 16mm Offset 22mm Lockable No Weight 0.44kg

Speaker Clamp Part No. G0728 Material Plastic Finish Black Weight 5g

Rectangular Glide Part No. F0690 Material 1.2mm Steel Finish Zink Weight 11g

High Quality, 600mm / 23.62" Deep, Wall Mount Rack Enclosures with: - Threaded Rack Rails -Integrated Internal Cable Management System -3-Fan Vents on the top -Cable Knock-Outs on the top, back and base -Lockable Front Door (choose from a Smoked Polycarbonate Door or Perforated Steel Door) Also Available in White Replacement Doors Available Part No. R6618 -M6 Material Steel Finish Black Description 18U Wall Mount Rack Cabinet Door Type Polycarbonate Weight 36kg

High Quality, 600mm / 23.62" Deep, Wall Mount Rack Enclosures with: - Threaded Rack Rails -Integrated Internal Cable Management System -3-Fan Vents on the top -Cable Knock-Outs on the top, back and base -Lockable Front Door (choose from a Smoked Polycarbonate Door or Perforated Steel Door) Also Available in White Replacement Doors Available Part No. R6612 -M6 Material Steel Finish Black Description 12U Wall Mount Rack Cabinet Door Type Polycarbonate Weight 31kg

Ester Foam - Grey. Premium quality Ester Foam, long lasting and will not discolor. Part No. M63025 Material Polyester Color Grey Thickness 25mm Full Sheet Size 2000mm x 1100mm Full Sheet Weight 2.25kg Half Sheet Size 1100mm x 1000mm Half Sheet Weight 1.125kg Quarter Sheet Size 1100mm x 500mm Quarter Sheet Weight 0.562kg

Large Ball Corner 3 Mounting Holes Part No. C1352 Z Material 1.5mm Steel Finish PennBrite Description Large Ball Corner Internal Radius 0.5mm Weight 76g

Mini Take Apart Hinge Dimensions: 26mm x 30mm Nickel Finish

Lockable Die-Cast Latch Part No. L0575 Material Die Cast Aluminium Finish Polished Chrome Weight 85g

Dish Punched for 1 x Neutrik D-Series Connector (XLR, Speakon, RJ45, etc.) Part No. D021K Material 1.2mm Steel Finish Black Dish Depth 16mm Weight 0.25kg

Dish Punched for 1 x Neutrik D-Series Connector (XLR, Speakon, RJ45, etc.) Part No. D021Z Material 1.2mm Steel Finish PennBrite Dish Depth 16mm Weight 0.25kg

Small Dish Punched for 1 x 1/4" Jack Connectors Part No. D0944 K Material 1.2mm Steel Dish Depth 13mm Weight 0.11kg

4 Hole Brace Part No. B1933 Material 1.5mm Steel Finish PennBrite Description 4 Hole Brace Dimensions 56mm x 35mm Internal Radius 5mm Weight 34g

Tray Support Part No. B1610 Material 1.2mm Steel Finish PennBrite Weight 18g

4 Hole Brace Part No. B0700 Material 1.2mm Steel Finish PennBrite Description 4 Hole Brace Dimensions 33.6mm x 25.4mm Internal Radius 1mm Weight 13g

6U Hinged Vented Rack Panel. Use with 1.5mm or 2mm Rack Rail: R0863 and R0883 Family Part No. R1272/6UVK Material 1.2mm Steel Finish Black Size (U) 6U Weight 1.17kg

Brace Ball Corner 6 Mounting Holes Part No. C1374 /00/75 Material 1.5mm Finish PennBrite Length 75mm Internal Radius 4.5mm Weight 0.1kg

Large Heavy Duty Ball Corner with 30mm Offset 6 Mounting Holes Part No. C1992Z Material 2.0mm Steel Finish PennBrite Description Large Heavy Duty Offset Ball Corner Internal Radius 4mm Weight 0.13kg
